Features

Single-Channel, 0.5 to 1-Msps, 12-Bit

Specified Over a Range of Sample Rates

6-Pin WSON and SOT-23 Packages

Variable Power Management

Single Power Supply With 2.7 V to 5.25 V Range

SPI, QSPI, MICROWIRE, and DSP Compatible

AEC-Q100 Grade 1 Qualified

DNL: +0.5 / 0.3 LSB (Typical)

INL: ±0.40 LSB (Typical)

Power Consumption:

– 3-V Supply: 2 mW (Typical)

– 5-V Supply: 10 mW (Typical)
